V86 2-Way On-Off Valve
Basic Ordering NumberEnd Connections Inlet & OutletOrificeCvDimensions mm(in.)Download
mm (in.)AHLSQ
V86A-D-4T1/4 in.DK-Lok4.8 (0.19)1.2108.3 (4.26)38.4 (1.52)97.12 (3.82)32.0 (1.26)[3D]V86A-D-4T.stp
D-6T3/8 in.DK-Lok7.1 (0.28)3.7104.5 (4.11)[3D]V86A-D-6T.stp
D-8T1/2 in.DK-Lok10.0 (0.39)7.5109.6 (4.31)[3D]V86A-D-8T.stp
F-4N1/4 in.Female NPT74.0 (2.91)[3D]V86A-F-4N.stp
F-6N3/8 in.Female NPT77.0 (3.03)[3D]V86A-F-6N.stp
F-8N1/2 in.Female NPT85.0 (3.35)[3D]V86A-F-8N.stp
M-4N1/4 in.Male NPT7.1 (0.28)3.795.4 (3.76)[3D]V86A-M-4N.stp
M-6N3/8 in. Male NPT10.0 (0.39)7.295.4 (3.76)[3D]V86A-M-6N.stp
M-8N1/2 in.Male NPT7.5100.2 (3.94)
V86B-F-8N1/2 in.Female NPT12.7 (0.50)10.1149.0 (5.86)50.8 (2.00)89.0 (3.50)40.0 (1.57)[3D]V86B-F-8N.stp
F-12N3/4 in.Female NPT90.0 (3.54)
D-12M12mmDK-Lok10.0 (0.39)112.6 (4.43)[3D]V86B-D-12M-P1.stp
D-16M16mmDK-Lok12.7 (0.50)115.0 (4.53)[3D]V86B-D-16M-P1.stp
D-8T1/2 in.DK-Lok10.4 (0.41)114.6 (4.51)
D-10T5/8 in.DK-Lok12.7 (0.50)114.4 (4.50)
D-12T3/4 in.DK-Lok114.8 (4.52)[3D]V86B-D-12T.stp
V86C-F-12N3/4 in.Female NPT19.0 (0.75)30149.0 (5.86)56.0 (2.20)96.0 (3.78)50.0 (1.97)[3D]V86C-F-12N.stp
F-16N1 in.Female NPT111.0 (4.37)[3D]V86C-F-16N.stp
D-12T3/4 in.DK-Lok15.7 (0.62)19125.0 (4.92)[3D]V86C-D-12T.stp
D-16T1 in.DK-Lok19.0 (0.75)30134.0 (5.27)[3D]V86C-D-16T.stp
M-12N3/4 in.Male NPT15.7 (0.62)19119.0 (4.68)
M-16N1 in.Male NPT19.0 (0.75)30129.0 (5.07)
V86 3-Way On-Off Valve
Basic Ordering NumberEnd ConnectionsOrificeDimensions mm(in.)SQDownload
mm (in.)AHH1L
V86A-3*- D-4T-1/4 in. DK-Lok4.8 (0.19)108.3 (4.26)38.4 (1.52)50.9 (2.0)97.12 (3.82)32.0 (1.26)[3D]V86A-3S-D-4T-P1.stp
3*- D-6T-3/8 in. DK-Lok7.1 (0.28)53.0 (2.09)104.5 (4.11)[3D]V86A-3S-D-6T-P1.stp
3*- D-8T-1/2 in. DK-Lok10.0 (0.39)55.8 (2.20)109.6 (4.31)[3D]V86A-3B-D-8T-P1.stp
3*- F-4N -1/4 in. Female NPT40.0 (1.57)74.0 (2.91)
3*- F-6N-3/8 in. Female NPT41.5 (1.64)77.0 (3.03)
3*- F-8N-1/2 in. Female NPT45.5 (1.79)85.0 (3.35)
V86B-3*- F-8N-1/2 in. Female NPT12.7 (0.50)149.0 (5.86)50.8 (2.00)55.0 (2.17)89.0 (3.50)40.0 (1.57)
3*- F-12N-3/4 in. Female NPT55.0 (2.17)90.0 (3.54)
3*- D-10T-5/8 in. DK-Lok67.2 (2.66)114.4 (4.50)
3*- D-12T-3/4 in. DK-Lok67.7 (2.66)115.0 (4.53)[3D]V86B-3S-D-12T-P1.stp
V86C-3*- D-12T-3/4 in. DK-Lok15.7 (0.62)149.0 (5.86)56.0 (2.20)75.3 (2.96)125.0 (4.92)50.0 (1.97)
3*- D-16T-1 in.DK-Lok19.0 (0.75)80.0 (3.15)134.0 (5.27)
3*- F-12N-3/4 in. Female NPT59.5 (2.34)96.0 (3.78)
3*- F-16N-1 in. Female NPT67.0 (2.64)111.0 (4.37)
VC86 2-Way On-Off Valve
Basic Ordering NumberEnd Connections Inlet & OutletOrificeCvDimensions mm(in.)Download
mm (in.)AHLSQ
VC86A-D-4T1/4 in.DK-Lok4.8 (0.19)1.2108.3 (4.26)38.4 (1.52)97.12 (3.82)32.0 (1.26)
D-6T3/8 in.DK-Lok7.1 (0.28)3.7104.5 (4.11)
D-8T1/2 in.DK-Lok10.0 (0.39)7.5109.6 (4.31)
F-4N1/4 in.Female NPT74.0 (2.91)
F-6N3/8 in.Female NPT77.0 (3.03)
F-8N1/2 in.Female NPT85.0 (3.35)
M-4N1/4 in.Male NPT7.1 (0.28)3.795.4 (3.76)
M-6N3/8 in. Male NPT10.0 (0.39)7.295.4 (3.76)
M-8N1/2 in.Male NPT7.5100.2 (3.94)
VC86B-F-8N1/2 in.Female NPT12.7 (0.50)10.1149.0 (5.86)50.8 (2.00)89.0 (3.50)40.0 (1.57)[3D]VC86B-F-8N.stp
F-12N3/4 in.Female NPT90.0 (3.54)[3D]VC86B-F-12N.stp
D-12M12mmDK-Lok10.0 (0.39)112.6 (4.43)[3D]VC86B-D-12M.stp
D-16M16mmDK-Lok12.7 (0.50)115.0 (4.53)[3D]VC86B-D-16M.stp
D-8T1/2 in.DK-Lok10.4 (0.41)114.6 (4.51)[3D]VC86B-D-8T.stp
D-10T5/8 in.DK-Lok12.7 (0.50)114.4 (4.50)
D-12T3/4 in.DK-Lok114.8 (4.52)[3D]VC86B-D-12T.stp
VC86C-F-12N3/4 in.Female NPT19.0 (0.75)30149.0 (5.86)56.0 (2.20)96.0 (3.78)50.0 (1.97)[3D]VC86C-F-12N.stp
F-16N1 in.Female NPT111.0 (4.37)[3D]VC86C-F-16N.stp
D-12T3/4 in.DK-Lok15.7 (0.62)19125.0 (4.92)[3D]VC86C-D-12T.stp
D-16T1 in.DK-Lok19.0 (0.75)30134.0 (5.27)
M-12N3/4 in.Male NPT15.7 (0.62)19119.0 (4.68)
M-16N1 in.Male NPT19.0 (0.75)30129.0 (5.07)
VC86D-F -16N1 in.Female NPT25.0 (0.98)Full Bore193.7 (7.62)84.1 (3.31)112.90 (4.44)70 (2.76)[3D]VC86D-F-16N.stp
